SMT DIP Rigid Flex Custom PCB Design Service Halogen Free Fr4
|Place of Origin||CHINA,VIETNAM,USA|
|Minimum Order Quantity||no MOQ|
|Packaging Details||ESD bag+card carton(custom made)|
|Delivery Time||5-10 weeks depends on components lead time|
|Payment Terms||L/C, T/T|
|Bare Board Size||Largest: 21.02’’ X 20.07’’ (534mm X 510mm)||Min. IC Pitch||0.012’’ (0.3mm)|
|QFN Lead Pitch||0.012’’ (0.3mm)||Max. BGA Size||2.90’’ X 2.90’’ (74mm X 74mm)|
|MiTestingn. BGA Size||0.012’’ (0.3mm)||Type Of Service||Turn-key, Partial Turn-key Or Consignment|
SMT DIP Custom PCB Design Service,
SMT DIP halogen free fr4 pcb,
Halogen Free Fr4 rigid flex pcb design
1, Factory Area:60000㎡ Shenzhen factory; two other factories in US and Vietnam.
2, Quality Control:IPC-1-610E Standard,E-test,X-ray,AOI Test,IQC,QC,QA,100% Functional Test
3, PCB Making (Rigid, Flexible,Rigid-Flexible,Aluminium, High TG,Ceramic), Component Sourcing, SMT&DIP, Free Program & Test, OEM/ODM Serivce
4, Certifcation:ATF 16949,ISO 13485,ISO 14001,ISO9001,UL(E326838),Disney FAMA, CE,FCC,ROHS,
|1||Material||PR4,Halogen free, High TG,CEM3,PTFE,Aluminum BT,Rogers|
|2||Board Thickness||Mass Production:0.3-3.5mm Samples:0.21-6.0mm|
|3||Surface Finish||HASL,OSP,Immersion Silver/Gold/SN,Flash Gold, Gold Finger,Hard Gold Plating|
|4||PCB Panel Size||Max Mass Productoin: 610x460mm Sample:762x508mm|
|5||Layer||Mass production:2-58 Layers, Samples:1-64 Layers|
|6||Min. Drill Hole Size||Laser Drill 0.1mm,Machine Drill 0.2mm|
|7||PCBA QC||X-ray,AOI Test,Functional Test|
|9||Sanforized||Buried via, Blind via, Mixed Pressure,Embedded Resistance,Embedded Capacitance, Local Mixed Pressure, Local High Density, Back Drill, Impedance Control|
1. What’s a motherboard?
A motherboard is a printed circuit assembly(PCA) used exclusively in laptop or desktop computers. While some may refer to a PCA as a motherboard,only those found in computers are motherboards. All other printed circuit assemblies are simply PCA or PCBA.
2.How does a printed circuit board assembly (PCB assembly) work?
The primary function of a PCB assembly is to integrate the electronic components of a device into a compact or defined space. Acting as the central hub of the electronic circuit of a device, the PCB provides insulation for all other electrical components, allowing them to be safely connected to a power source.
3. What information is required for a turnkey PCB assembly order?
For turnkey projects, we’ll need the following:
Bill of materials (BOM)
Component placement list (CPL)
All relevant CAD and .stp file
4. Are you UL / Underwriters Laboratory approved?
IBE pursues all applicable UL certifications for our products, and we offer several products certified with UL and CSA based on customer’s demand
Underwriters Laboratories (UL) grants multiple certifications, including:
IBE is certified for PCB by UL file E326838
5. Do you offer RoHS&REACH-compliant assemblies?
Yes, IBE does offer assemblies that comply with the European Union’s Restriction of Hazardous Substances (RoHS) Directive and REACH.
6. Do you offer testing and inspection services?
Yes, IBE offers a comprehensive list of testing and inspection services for both SMT and through-hole assemblies.
Visual inspection/scanning microscopes
Functional testing include automated test equipment and system
Low/High Temp Chamber Testing
X-ray inspection and repair
Salt fog tester
Conformal coating and potting
7. What are your PCB assembly standards?
IBE has obtained the following IPC electronics industry standards for PCB assembly
IPC-A-600G for PCB production
IPC-620 for practices and requirements for cables, wire, and harness assembly manufacturing
IPC-A-610E PCBA Acceptability of Electronic Assemblies
8.Can you ship to my contract manufacturer for the final build?
Yes, we can ship your assemblies for final production. We can also offer turnkey, box build, and labor-only services
9.Where do you manufacture your products?
We have production plant based in shenzhen,China; Fremont,US,Bac Ninh,Vietnam, where to produce it depends on customer.
