Gold Detector One Stop 94v0 PCB Assembly IPC-A-600G Class II

Brand Name IBE
Certification IATF16949,ISO13485,ISO 9001,ISO14001,ISO45001,UL,FDA
Model Number IBE-9284
Minimum Order Quantity 1pc
Price $USD3.5-4.8 unit
Packaging Details ESD bag+card carton(custom made)
Delivery Time 4-20 weeks depends on components lead time
Payment Terms L/C, T/T
Supply Ability 200000pcs
Product Details
Colour White,yellow Name Pcb Assembly
Surface Technical LF-HASL Layer Count 2
Material FR4 Tg150 Max Panel Size 750mm*708mm
Acceptable Standard IPC-A-600G Class II Or III Service One-stop Quick Turnkey Service
Test AOI,FCT,ICT Other Service Pcb Layout
High Light

Gold Detector 94v0 pcb assembly


94v0 PCB Assembly IPC-A-600G Class II


Gold Detector one stop pcb assembly

Leave a Message
Product Description

Customized Turnkey PCB Board Fabrication Gold Detector PCB Assembly Manufacturer in Shenzhen,Vietnam and US


These detector pcb assembly are made of highly conductive materials and possess distinct line spacing lengths. The design of the Metal Detector Pcb Assembly is based on the eddy current generated in the metal conductor when the eddy current sensor detects the coil near the metal object, which increases the energy loss in the oscillating circuit, weakens the positive feedback, and weakens the oscillation of the oscillator.


Gold Detector One Stop 94v0 PCB Assembly IPC-A-600G Class II 0

About IBE Corporation

IBE keeps making breakthroughs in technology and production to lead the EMS industrial and build a one-stop solution integrating material purchasing, production processing and finished
product reliability test which enable our customer to achieve meaningful time to market and save cost.
Our products are widely applied in Automotive,Medical,Defense and Aerospace,Power Supply,Smart Metering industry,etc.
We've good cooperation with many famous enterprises,such as Flextronics,Foxconno,ABB,AEC,Jabil,Valeo,Bushnell,Sanmina, Grammer and so on.
High quality and competitive price let IBE obtain the trust of our clients from all over the world.
With strong manufacturing and producing capacities and the practical application in all fields,IBE Group has achieved stable increase of sales volume year by year.
Since established in 1998,over 20 years of innovation and development,IBE Group has set up four processing and manufacturing bases including the headquarters in Shenzhen, and a manufacturing factory in Portland,America.In addition, our EMS factory in Vietnam.
Gold Detector One Stop 94v0 PCB Assembly IPC-A-600G Class II 1
Gold Detector One Stop 94v0 PCB Assembly IPC-A-600G Class II 2


Certified by ISO 9001 and 14001,IBE is a well-equipped and strictly managed manufacturer.We integrate our resources and manage production through MES system which can well optimize process and guarantee quality.Besides,IBE Group adheres strictly to the production and manufacturing standards of IATF16949,automobile industry and ISO 13485,medical industry.


Gold Detector One Stop 94v0 PCB Assembly IPC-A-600G Class II 3

Q: What service do you have?
A: We provide PCB,components sourcing,PCB assembly,box build,R &D services.

Q: What is your minimum order quantity (MOQ)?
A:As for MOQ, we have no request about it. Even 1 pcs is ok for us.

Q: What is needed for PCB & PCBA quotation?
A: Gerber fie,Bom list and production technical requirements.

Q: How to keep our product information and design file secret ?
A: We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
