1.6mm FR4 Electronic PCBA Contract Manufacturing Service SMT
Min. Line Width | 0.075mm/0.075mm(3mil/3mil) | Surface Finishing | ENIG |
---|---|---|---|
Copper Thickness | 1oz | Base Material | FR4 |
Min. Line Spacing | 0.075mm | Board Thickness | 1.6mm |
Min. Hole Size | 0.25mm | Soldermask Color | Green |
Silkscreen Color | White | Layer | 1-32L |
High Light | 1.6mm FR4 Electronic PCBA,FR4 pcba contract manufacturing,SMT contract electronic assembly |
Electronics PCB Board PCBA Assembly with Contract Manufacturing Service
Since 2005, IBE provides Electronics Manufacturing Service (EMS) in China,US,Vietnam. As an ISO 9001 , UL,CSA and CCC certified manufacturer, We offers flexible, cost effective and high quality EMS solutions for printed circuit board assembly (PCBA) and complete product assembly through state of the art manufacturing technologies and production facilities.
With over 15 years manufacturing experience in electronics sectors, IBE is more than a reliable EMS provider for OEMs. Aiming at top notch manufacturing service and total customer satisfaction, we have maintained long term business partnerships with customers all around the world. Our products are mainly applied in the Consuming, Industrial, Automation, Automotive, Agriculture, Defense, Aerospace, Medical and Security markets.
Our factory equipped with a variety of assembly technologies including Surface Mount Machine, PTH Insertion, COB, BGA, Flip, Wire Bonding, Box Build and Lead Free Soldering. Our production fact sheet is as following.
PCBA Capability
The main SMT production line consists of automated high-precision state-of-the-art equipments from PanasonIC,Sumsung, Japan total 6 lines (Smallest SMT components size can reach to 0201,capable of 0.6mm*0.3mm ~ 50mm*50mmQFP, 0.15mm gap, ±0.05 accuracy ),
EMS capacity can reach 150,000,000 components per month.
Our engineering team has extensive experience in DFM/DFA/DFT technologies.
SMT, BGA Rework, Re-balling, X-Ray are all readily achieveable. Stencils can
be cut and delivered inside of 4 hours.
PCB Manufacturing Capability | |
PCB Layers: | 1Layers to 18 layer (Max) |
Board thickness: | 0.13~6.0mm |
Min line width/space: | 3mil |
Min mechanical hole size: | 4mil |
Copper thickness: | 9um~210um(0.25oz~6oz) |
Max aspect ratio: | 1:10 |
Max board size: | 400*700mm |
Surface Finish: | HASL, immersion gold, immersion silver,immersion tin, flash gold, gold finger,peelable mask |
Material: | FR4,High Tg, Rogers, CEM-1, CEM-3, Aluminum BT, PTFE. |
PCB Assembly Capability | |
Stencil size range: | 1560*450mm |
Min SMT package: | 0402/1005(1.0x0.5mm) |
Min IC pitch: | 0.3mm |
Max PCB Size: | 1200*400mm |
Min PCB thickness: | 0.35mm |
Min Chip Size: | 01005 |
Max BGA Size: | 74*74mm |
BGA Ball Pitch: | 1.00~3.00mm |
BGA Ball Diameter: | 0.4~1.0mm |
QFP Lead Pitch: | 0.38~2.54mm |
Testing : | ICT,AOI,X-RAY,Funtional test etc. |
Order Conditions
|
Standard Delivery Date
|
The fastest Delivery Date
|
Prototype ( <20pcs)
|
2days
|
8hours
|
Small Volume (20-100pcs)
|
6days
|
12hours
|
Medium Volume (100-1000)
|
3days
|
24hours
|
Mass Production (>1000)
|
Depends on BOM
|
Depends on BOM
|
FAQ:
1. What’s a motherboard?
1.How does a printed circuit board assembly (PCB assembly) work?
The primary function of a PCB assembly is to integrate the electronic components of a device into a compact or defined space. Acting as the central hub of the electronic circuit of a device, the PCB provides insulation for all other electrical components, allowing them to be safely connected to a power source.
2. What information is required for a turnkey PCB assembly order?
For turnkey projects, we’ll need the following:
Gerber file
Bill of materials (BOM)
Component placement list (CPL)
All relevant CAD and .stp file
3. Are you UL / Underwriters Laboratory approved?
IBE pursues all applicable UL certifications for our products, and we offer several products certified with UL and CSA based on customer’s demand
Underwriters Laboratories (UL) grants multiple certifications, including:
IBE is certified for PCB by UL file E326838
